Rivard Bora

Rivard Bora Image

SPECIFICATIONS

Carrier-mounted equipment
TOYOTA HILUX euro 6 version 4×4
150 hp
Air conditioning/Parking radar/Bluetooth radio
Height : 1 820 mm
Length : 5 330 mm
Towing possibility : 3 500 kg
Capacity
Total volume 1 200 l/aluminium tank
– Water capacity 400 l
– Sludge capacity 800 l
Vacuum pump
– Forced air cooled rotating
360 m3/hr in free flow
or power possibility to drive a transfer pump (optional)
Jetting pump
– 41 hp power
30 l/min at 450 bar
37 l/min at 400 bar
46 l/min at 300 bar
90 l/min at 150 bar
HP reel
100 m capacity in 1/2″ or 80 m in 5/8″
With possibility of working with the door closed
Sludge tank filling reel
30 m in DN 50 positioned horizontally, avoiding the need to
take the hose out completely to work
Water tank filling
– Direct to the tank OR by
filling reel, 25 m capacity in DN 19 (optional)
Possibility of working with continuous filling
Compartment and storage
– High capacity, lockable storage areas dedicated to precise
uses (force camera, suction, water/dust, cones, PPE, etc.)
600 l volume
Electrical equipment
Control panel at the rear of the equipment
Control unit + functional information on 2.8″ IP66 colour
control screen
2 radio controls
Operator safety
– Engine start/stop by remote control
– Sludge tank emptying by independent “flushing system”
– Rear view camera (optional)
– Reversing radar
– Emergency stop punch button
Conformity
– EC 2006/42
– Highway code according to current regulations
Options
– Heater for the whole equipment
– Storage compartment LED lighting
– Pedestrian zone lighting
– Colour rear view camera
– 12 Vcc/230 Vac-300 W converter
– Dosing pump
– Flashing light and LED AK5 panel
– 15 HP hydraulic pre-fitting
– 25 m DN 19 filling reel
– Reel : 40 m and remote antenna
